Master the Heat. Define the Precision
1 Years
| Ask Lasest Price | |
| Brand Name : | InductionFusion |
| Model Number : | IF-40 |
| Certification : | CE, SGS , ROHS |
| Price : | negotiation |
| Payment Terms : | T/T,Western Union |
| Supply Ability : | 500set/month |
| Delivery Time : | 7~15days |
| Work power | 360V-520V |
| Maximum input current | 65A |
| Output power | 40kw |
| Fluctuating frequency | 20-50khz |
| Output current | 400-1800A |
| The flow rate of cooling water | 0.08-0.16Mpa 9L/Min |
| Water temperature protection point | 50C |
| Product size | main : 690x600x1060mm |
| transformer : 570x290x470mm | |
| Net weight | main : 60kgs |
| transformer : 28kgs |
Major Features
CE Approved Induction Melting Equipment Ultrahigh Frequency Induction Heating 40KW adopts Soft-switch ultrahigh frequency technology and two poles closed loop control technology; and our company fully owns the independent intellectual property rights
Fluctuating frequency can be 100K-1.5MHZ, control the depth of surface quenching, which can totally replace the high frequency of vacuum tube.
CE Approved Induction Melting Equipment Ultrahigh Frequency Induction Heating 40KW can continuously work for 24 hours, and 100% duty cycle.
Parts of power devices are all from well-know brand products
Ultra-small size and weight; High efficiency, energy saving and environmental protection with safety.
|
|
